Solar power can provide electricity for many applications.
In very remote locations it may be the only practical solution since reliable power can be provided virtually anywhere. In addition, more and more residential and commercial customers are realizing the benefits of utilizing solar power for electricity to offset their utility-supplied energy consumption, to provide back up power or to operate independent of the utility grid. Solar power can be a solution paneles solares guatemala .
Advanced Energy Group is a trusted and respected supplier of reliable solar power as well as back up power systems throughout the United States and in many other countries. We are known for using the highest quality solar panels and related components when integrating solar power into your project, and we provide a high level of responsive, expert technical support to our customers.
Get all your equipment and supplies to use solar power and small class wind power.Balance of system components. We carry all necessary components to integrate solar power into your project including solar panels, mounting structures, solar controllers, inverters, batteries, enclosures, wiring and fittings. So whether you need a few watts a day or a mega-watt we can provide the complete power system package. We also offer custom engineering for specialty structures and enclosures, and we can even skid-mount and ship your power unit fully operational. Utilizing solar power has never been easier, and doing business has never been more reliable when you build your power system with us. We provide complete technical assistance and the finest equipment when utilizing solar power to insure a successful project. We have everything you need.
Other quality devices using solar power. Besides providing much larger integrated systems we also offer a small selection of hand picked quality devices that utilize solar power such as a portable AC/DC unit, a hand or solar powered water pump and a solar powered vent fan. These are great devices for a variety of uses, and they are all listed on our equipment page.
Advanced Energy Group – We can help you utilize solar power for your remote site, residential or commercial project.
Develop the potential of solar power with confidence!
Get high quality equipment, expert technical support and excellent pricing.
The Basics of Solar Power for Producing Electricity
Learn the essential basics of using solar power so you can understand your project.
Planning your project begins with understanding the basics found in this section.
An excellent place to start for those just beginning.
Solar power works well for most items except large electric appliances that use an electric heat element such as a water heater, clothes dryer and electric stove – for example – or total electric home heating systems. It is not cost effective to use solar power for these items. Conversion to natural gas, propane or other alternatives is usually recommended. Solar power can be used to operate a gas clothes dryer (Maytag, etc) because the electrical requirement is limited to the drum-motor and/or ignito-lighter, but not a HEAT element for drying the clothes, for example.
We recommend you also review our page Helpful Solar Power Glossary which will provide useful terms and General Construction TechniquesÂ for insight into energy efficient new construction or retrofitting energy efficient principles into your building project.
The basics of solar power:
Using solar power to produce electricity is not the same as using solar to produce heat. Solar thermal principles are applied to produce hot fluids or air. Photovoltaic principles are used to produce electricity. A solar panel (PV panel) is made of the natural element, silicon, which becomes charged electrically when subjected to sun light.
Solar panels are directed at solar south in the northern hemisphere and solar north in the southern hemisphere (these are slightly different than magnetic compass north-south directions) at an angle dictated by the geographic location and latitude of where they are to be installed. Typically, the angle of the solar array is set within a range of between site-latitude-plus 15 degrees and site-latitude-minus 15 degrees, depending on whether a slight winter or summer bias is desirable in the system. Many solar arrays are placed at an angle equal to the site latitude with no bias for seasonal periods.
This electrical charge is consolidated in the PV panel and directed to the output terminals to produce low voltage (Direct Current) – usually 6 to 24 volts. The most common output is intended for nominal 12 volts, with an effective output usually up to 17 volts. A 12 volt nominal output is the reference voltage, but the operating voltage can be 17 volts or higher much like your car alternator charges your 12 volt battery at well over 12 volts. So there’s a difference between the reference voltage and the actual operating voltage
The intensity of the Sun’s radiation changes with the hour of the day, time of the year and weather conditions. To be able to make calculations in planning a system, the total amount of solar radiation energy is expressed in hours of full sunlight per m², or Peak Sun Hours. This term, Peak Sun Hours, represents the average amount of sun available per day throughout the year.
It is presumed that at “peak sun”, 1000 W/m² of power reaches the surface of the earth. One hour of full sun provides 1000 Wh per m² = 1 kWh/m² – representing the solar energy received in one hour on a cloudless summer day on a one-square meter surface directed towards the sun. To put this in some other perspective, the United States Department of Energy indicates the amount of solar energy that hits the surface of the earth every +/- hour is greater than the total amount of energy that the entire human population requires in a year. Another perspective is that roughly 100 miles square of solar panels placed in the southwestern U.S. could power the country.
The daily average of Peak Sun Hours, based on either full year statistics, or average worst month of the year statistics, for example, is used for calculation purposes in the design of the system. To see the average Peak Sun Hours for your area in the United States, you can click the following link which will open a new window – just close it. when you’re done to return here; U.S.-Solar Insolation Choose the area closest to your location for a good indication of your average Peak Sun Hours.
